Puretec String Wound Sediment Cartridge

String Wound Sediment Cartridge

The Puretec GW Series wound sediment cartridges are cost-effective solutions for the reduction of sand, silt, rust, dirt and scale particles. The GW Series are wound in a precise pattern around the core providing greater surface area. The result is a higher dirt-holding capacity and greater efficiency than standard wound cartridges.

• String-wound design.
• High dirt-holding capacity.
• Large range, options for course to sediment.

SPECIFICATIONS

Ordering Code: GW502
Micron Rating: 50
Size: Standard 2.5" X 20"
Flow Rate: 84

Ordering Code: GW501
Micron Rating: 50
Size: Standard 2.5" X 10"
Flow Rate: 42

Ordering Code: GW202
Micron Rating: 20
Size: Standard 2.5" X 20"
Flow Rate: 76

Ordering Code: GW201
Micron Rating: 20
Size: Standard 2.5" X 10"
Flow Rate: 38

Ordering Code: GW101
Micron Rating: 10
Size: Standard 2.5" X 10"
Flow Rate: 32

Ordering Code: GW05LD2
Micron Rating: 5
Size: Large Diameter 4.5" X 20"
Flow Rate: 152

Ordering Code: GW05LD1
Micron Rating: 5
Size: Large Diameter 4.5" X 10"
Flow Rate: 76

Ordering Code: GW052
Micron Rating: 5
Size: Standard 2.5" X 20"
Flow Rate: 54

Ordering Code: GW051
Micron Rating: 5
Size: Standard 2.5" X 10"
Flow Rate: 27

Ordering Code: GW01LD2
Micron Rating: 1
Size: Large Diameter 4.5" X 10"
Flow Rate: 150

Ordering Code: GW01LD1
Micron Rating: 1
Size: Large Diameter 4.5" X 10"
Flow Rate: 75

Ordering Code: GW012
Micron Rating: 1
Size: Standard 2.5" X 20"
Flow Rate: 52

Ordering Code: GW011
Micron Rating: 1
Size: Standard 2.5" X 10"
Flow Rate: 26
